PLTC/ITC 300V Pairs/Triads & Overall Shield PVC, PVC, OS
Conductor: 20 AWG through 16 AWG bare, annealed copper per ASTM B3. Class B stranding per ASTM B8.
Insulation: Lead-free Polyvinyl Chloride (PVC). Color-coded per ICEA Method 1: Pairs – black and white; Triads – black, white and red. One conductor in each pair or triad is printed alphanumerically for easy identification.
Jacket: Lead-free, sunlight-resistant Polyvinyl Chloride (PVC).
Shield: Yes
Voltage: 300V
More details…
PLTC/ITC 300V Pairs & Overall Shield PVC, PVC, SPOS
Conductor: 20 AWG through 16 AWG bare, annealed copper per ASTM B3. Class B stranding per ASTM B8.
Insulation: Lead-free Polyvinyl Chloride (PVC). Color-coded per ICEA Method 1: Pairs – black and white. One conductor in each pair is printed
alphanumerically for easy identification; Triads – black, white and red. One conductor in each pair or triad is printed alphanumerically for easy identification.
Jacket: Lead-free, sunlight-resistant Polyvinyl Chloride (PVC).
Shield: Yes
Voltage: 300V
More details…
PLTC/ITC 300V Triads & Overall Shield PVC, PVC, STOS
Conductor: 20 AWG through 16 AWG bare, annealed copper per ASTM B3. Class B stranding per ASTM B8.
Insulation: Lead-free Polyvinyl Chloride (PVC). Color-coded per ICEA Method 1: Triads – black, white and red. One conductor in each triad is printed alphanumerically for easy identification.
Jacket: Lead-free, sunlight-resistant Polyvinyl Chloride (PVC).
Shield: Yes
Voltage: 300V
More details…
TC-ER 600V Pairs & Overall Shield PVC/Nylon, PVC, SPOS
Conductor: 18 AWG and 16 AWG bare, annealed copper per ASTM B3. Class B stranding per ASTM B8.
Insulation: Flame-retardant Polyvinyl Chloride (PVC) with clear Polyamide (nylon). Color-coded per ICEA Method 1: Pairs – black and white. One conductor in each pair is printed alphanumerically for easy identification.
Jacket: Lead-free, sunlight-resistant Polyvinyl Chloride (PVC).
Shield: Yes
Voltage: 600V
More details…
TC-ER 600V Triads & Overall Shield PVC/Nylon, PVC, STOS
Conductor: 18 AWG and 16 AWG bare, annealed copper per ASTM B3. Class B stranding per ASTM B8.
Insulation: Flame-retardant Polyvinyl Chloride (PVC) with clear Polyamide (nylon). Color-coded per ICEA Method 1: Triads – black, white and red. One conductor in each triad is printed alphanumerically for easy identification.
Jacket: Lead-free, flame-retardant, sunlight-resistant Polyvinyl Chloride (PVC)..
Shield: Yes
Voltage: 600V
More details…
TC-ER 600V Pairs/Triads Shield FR-EPR, CPE, OS
Conductor: 18 AWG and 16 AWG tinned, annealed copper per ASTM B33. Class B stranding per ASTM B8.
Insulation: Flame-retardant Ethylene Propylene Rubber (FR-EPR) Type II. Color-coded per ICEA Method 1: Pairs – black and white; Triads – black, white and red. One conductor in each pair is printed alphanumerically for easy identification.
Jacket: Lead-free, flame-retardant, thermoplastic Chlorinated Polyethylene (CPE).
Shield: Yes
Voltage: 600V
More details…
TC-ER 600V Pairs & Overall Shield FR-EPR, CPE, SPOS
Conductor: 18 AWG and 16 AWG tinned, annealed copper per ASTM B33. Class B stranding per ASTM B8.
Insulation: Flame-retardant Ethylene Propylene Rubber (FR-EPR) Type II. Color-coded per ICEA Method 1: Pairs – black and white. One conductor in each pair is printed alphanumerically for easy identification.
Jacket: Lead-free, flame-retardant, thermoplastic Chlorinated Polyethylene (CPE).
Shield: Yes
Voltage: 600V
More details…
TC 600V Pairs/Triads & Overall Shield LS-XLP, LSZH, OS
Conductor: 18 AWG and 16 AWG tinned, annealed copper per ASTM B33. Class B stranding per ASTM B8.
Insulation: Lead-free, flame-retardant, low-smoke, Cross-Linked Polyethylene (XLPE). Color-coded per ICEA Method 1: Pairs – black and white. Triads – black, white and red. One conductor in each pair or triad is printed alphanumerically for easy identification.
Jacket: Lead-free, flame-retardant, sunlight-resistant, Low-Smoke, Zero-Halogen Polyolefin (LSZH).
Shield: Yes
Voltage: 600V
More details…
TC 600V Pairs Overall Shield LS-XLP, LSZH, SPOS
Conductor: 18 AWG and 16 AWG tinned, annealed copper per ASTM B33. Class B stranding per ASTM B8.
Insulation: Lead-free, flame-retardant, low-smoke, Cross-Linked Polyethylene (XLPE). Color-coded per ICEA Method 1: Triads – black, white and red. One conductor in each triad is printed alphanumerically for easy identification.
Jacket: Lead-free, flame-retardant, sunlight-resistant, Low-Smoke, Zero-Halogen Polyolefin (LSZH).
Shield: Yes
Voltage: 300V
More details…
TC 600V Triads & Overall Shield LS-XLP, LSZH, STOS
Conductor: 18 AWG and 16 AWG tinned, annealed copper per ASTM B33. Class B stranding per ASTM B8.
Insulation: Lead-free, flame-retardant, low-smoke, Cross-Linked Polyethylene (XLPE). Color-coded per ICEA Method 1: Triads – black, white and red. One conductor in each triad is printed alphanumerically for easy identification.
Jacket: Lead-free, flame-retardant, sunlight-resistant, Low-Smoke, Zero-Halogen Polyolefin (LSZH).
Shield: Yes
Voltage: 300V
More details…
